High Sensitivity Temperature Measuring Walkthrough Metal Detector
Product Introduction
High Sensitivity Temperature Measuring Walkthrough Metal Detector (Upgrade),Based on the traditional metal detection, the human body surface temperature is initially detected by a thermal imager (noncontact type) to find individuals with abnormal temperature. After the abnormal temperature target is found, professional temperature measurement is performed to effectively control the source of infection. Example: 100 people pass the screening and find that 20-30 people have abnormal temperature targets, and then use professional methods to measure and confirm, which can effectively reduce the testing workload and improve efficiency.
Product Features
- Screening of human body temperature through thermal imaging
- High detection accuracy, detecting people with abnormal body temperature, preset temperature threshold alarm
- Designed for crowded places to meet the needs of fast customs clearance
- Can be divided into up to 24 detection areas, each area sensitivity can be individually set up to 300 sensitivity calibration
Applications
- Airports
- Malls
- Hotels
- Hospitals
- Schools
- Stations
- Customs
- Highways
- Venues
- Public space indoor
Technology Data of Thermal Imaging
- Detector type…………...........Vanadium oxide uncooled infrared focal plane
- Detector resolution…..........256 x 192
- Temperature measurement accuracy....... ± 0.3℃(with black body)
- Temperature measurement range………… 30 - 45℃
- Spectral range…………................ 8μm-14μm
- Thermal imaging lens………3.5mm/7mm(can choose)
- Sensitivity.............………….......<50mK
- Visible light....……………….......1/2.8°CMOS,1080P
- Visible light lens………………..4mm/8mm(can choose)
- Sound and light alert……….Built-in white light warning light & horn
